FEATURED PRODUCT
Matrix Switch
The purpose of the unit is to provide protection to the RF power amplifiers and/or radios due to damage to antenna systems or connection to inappropriate antennas. This can be used as a standalone product or in conjunction with our tuneable filter and/or fixed filters.
TECHNICAL SPECIFICATIONS
Blocking switches
Switches are available in 4x4, 6x6, 10x10 and 12x12 configurations
Configurations up to 24x24 can be developed on request
Latching and non-latching switches available (latching is standard)
2 –28V operating voltage
SMA input and TNC output connectors (swappable on request)
Features front panel control; RSxxx USB and Ethernet communication
Frequency range DC -26.5GHz
Power rating 5kW @ 1-100MHz, 1kW @ 1-1Ghz
Suitable for land, sea and air operation
Option of 3103 or 3106 stainless steel housing
